Activiti

@Override
public void publish(Long id) {
    // 修改状态
    ProcessTemplate processTemplate = baseMapper.selectById(id);
    // 获取定义文件的路径
    String path = processTemplate.getProcessDefinitionPath();
    if (StringUtils.isEmpty(path)) {
        throw new BizException("文件路径为空");
    }
    deployByZip(path);
    processTemplate.setStatus(1);
    baseMapper.updateById(processTemplate);
}

private void deployByZip(String path) {
    InputStream inputStream = this.getClass().getClassLoader().getResourceAsStream(path);
    ZipInputStream zipInputStream = new ZipInputStream(inputStream);
    // 流程部署
    Deployment deployment = repositoryService.createDeployment()
            .addZipInputStream(zipInputStream)
            .deploy();
}

@Override
public void startUp(ProcessFormVo processFormVo) {
    // 获取用户信息
    SysUser sysUser = sysUserService.getById(LoginUserInfoHelper.getUserId());
    // 根据审批模版id，查询模板信息
    LambdaQueryWrapper<ProcessTemplate> wrapper = new LambdaQueryWrapper<>();
    wrapper.select(ProcessTemplate::getId, ProcessTemplate::getName, ProcessTemplate::getProcessDefinitionKey)
            .eq(ProcessTemplate::getId, processFormVo.getProcessTemplateId());
    ProcessTemplate processTemplate = processTemplateService.getOne(wrapper);
    // 保存流程信息
    Process process = new Process();
    BeanUtils.copyProperties(processFormVo, process);
    process.setStatus(1);
    String workNo = String.valueOf(System.currentTimeMillis());
    process.setProcessCode(workNo);
    process.setUserId(LoginUserInfoHelper.getUserId());
    process.setFormValues(processFormVo.getFormValues());
    process.setTitle(sysUser.getName() + "发起" + processTemplate.getName() + "申请");
    baseMapper.insert(process);
    // 启动流程实例
    // 流程定义key
    String key = processTemplate.getProcessDefinitionKey();
    // 业务流程id
    String businessId = String.valueOf(process.getId());
    // 流程参数
    HashMap<String, Object> variables = new HashMap<>();
    JSONObject jsonObject = JSON.parseObject(processFormVo.getFormValues());
    JSONObject formData = jsonObject.getJSONObject("formData");
    HashMap<String, Object> map = new HashMap<>(formData);
    variables.put("data", map);
    ProcessInstance processInstance = runtimeService.startProcessInstanceByKey(key, businessId, variables);
    // 查询下一个审批人
    List<Task> taskList = this.getCurrentTaskList(processInstance.getId());
    String names = taskList.stream().map(task -> {
        String assignee = task.getAssignee();
        SysUser user = sysUserService.getUserByUsername(assignee);
        // 推送消息
      	messageService.pushPendingMessage(process, user, task.getId());
        return user.getName();
    }).collect(Collectors.joining(","));
    // 业务流程关联
    process.setProcessInstanceId(processInstance.getId());
    process.setDescription("等待" + names + "审批");
    baseMapper.updateById(process);
    processRecordService.record(process.getId(), 1, "发起申请");
}

@Override
public Map<String, Object> show(Long id) {
    // 获取审批信息
    Process process = baseMapper.selectById(id);
    if (process == null) return null;
    // 获取审批记录信息
    LambdaQueryWrapper<ProcessRecord> wrapper = new LambdaQueryWrapper<>();
    wrapper.eq(ProcessRecord::getProcessId, id);
    List<ProcessRecord> processRecords = processRecordService.list(wrapper);
    // 获取审批模版
    ProcessTemplate processTemplate = processTemplateService.getById(process.getProcessTemplateId());
    // 是否可以审批
    List<Task> taskList = this.getCurrentTaskList(process.getProcessInstanceId());
    boolean isApprove = false;
    for (Task task : taskList) {
        String username = LoginUserInfoHelper.getUsername();
        if (task.getAssignee().equals(username)) {
            isApprove = true;
            break;
        }
    }
    // 封装map数据
    HashMap<String, Object> map = new HashMap<>();
    map.put("process", process);
    map.put("processRecordList", processRecords);
    map.put("processTemplate", processTemplate);
    map.put("isApprove", isApprove);
    return map;
}

@Override
public void approve(ApprovalVo approvalVo) {
    // 获取流程变量
    String taskId = approvalVo.getTaskId();
    Process process = baseMapper.selectById(approvalVo.getProcessId());
    Map<String, Object> variables = taskService.getVariables(taskId);
    if (approvalVo.getStatus() == 1) {
        // 审批通过
        taskService.complete(taskId);
    } else {
        // 驳回
        this.endTask(taskId);
    }
    // 推送给发起人
    messageService.pushProcessedMessage(process, approvalVo.getStatus());
    // 记录审批过程信息
    String description = approvalVo.getStatus() == 1 ? "已通过" : "已拒绝";
    processRecordService.record(approvalVo.getProcessId(), approvalVo.getStatus(), description);
    // 查询下一个审批人
    List<Task> taskList = this.getCurrentTaskList(process.getProcessInstanceId());
    if (!CollectionUtils.isEmpty(taskList)) {
        String names = taskList.stream().map(task -> {
            String assignee = task.getAssignee();
            SysUser user = sysUserService.getUserByUsername(assignee);
            // 推送消息
            messageService.pushPendingMessage(process, user, task.getId());
            return user.getName();
        }).collect(Collectors.joining(","));
        process.setDescription("等待" + names + "审批");
        process.setStatus(1);
    } else {
        if (approvalVo.getStatus() == 1) {
            process.setDescription("审批完成（通过）");
            process.setStatus(2);
        } else {
            process.setDescription("审批完成（通过）");
            process.setStatus(-1);
        }
    }
    baseMapper.updateById(process);
}

// 结束流程
private void endTask(String taskId) {
    // 获取任务对象
    Task task = taskService.createTaskQuery().taskId(taskId).singleResult();
    // 获取流程定义模型
    BpmnModel bpmnModel = repositoryService.getBpmnModel(task.getProcessDefinitionId());
    // 获取结束流程节点
    List<EndEvent> endEventList = bpmnModel.getMainProcess().findFlowElementsOfType(EndEvent.class);
    if (CollectionUtils.isEmpty(endEventList)) {
        return;
    }
    FlowNode endFlowNode = (FlowNode) endEventList.get(0);
    // 当前流向节点
    FlowNode currentFlowNode = (FlowNode) bpmnModel.getMainProcess().getFlowElement(task.getTaskDefinitionKey());

    // 临时保留当前活动的原始流向
    // List<SequenceFlow> originalSequenceFlowList = new ArrayList<>(currentFlowNode.getOutgoingFlows());
    // 清理当前流向节点
    currentFlowNode.getOutgoingFlows().clear();

    // 创建新流向
    SequenceFlow newSequenceFlow = new SequenceFlow();
    newSequenceFlow.setId("newSequenceFlow");
    newSequenceFlow.setSourceFlowElement(currentFlowNode);
    newSequenceFlow.setTargetFlowElement(endFlowNode);

    // 当前节点指向新方向
    ArrayList<SequenceFlow> newSequenceFlows = new ArrayList<>();
    newSequenceFlows.add(newSequenceFlow);
    currentFlowNode.setOutgoingFlows(newSequenceFlows);

    taskService.complete(taskId);
}

@Override
public IPage<Process> pageStarted(Page<Process> pageParam) {
    LambdaQueryWrapper<Process> wrapper = new LambdaQueryWrapper<>();
    wrapper.eq(Process::getUserId, LoginUserInfoHelper.getUserId());
    return baseMapper.selectPage(pageParam, wrapper);
}

@Override
public IPage<ProcessVo> pageProcessed(Page<Process> pageParam) {
    // 封装查询信息
    HistoricTaskInstanceQuery query = historyService.createHistoricTaskInstanceQuery()
            .taskAssignee(LoginUserInfoHelper.getUsername())
            .finished()
            .orderByTaskCreateTime().desc();
    // 分页查询已完成的任务
    int begin = (int) ((pageParam.getCurrent() - 1) * pageParam.getSize());
    int size = (int) pageParam.getSize();
    List<HistoricTaskInstance> list = query.listPage(begin, size);
    List<ProcessVo> processVoList = new ArrayList<>();
    for (HistoricTaskInstance item : list) {
        // 根据流程实例ID获取流程信息
        LambdaQueryWrapper<Process> wrapper = new LambdaQueryWrapper<>();
        wrapper.eq(Process::getProcessInstanceId, item.getProcessInstanceId());
        Process process = baseMapper.selectOne(wrapper);
        // 转换
        ProcessVo processVo = new ProcessVo();
        BeanUtils.copyProperties(process, processVo);
        processVo.setTaskId(item.getId());
        processVoList.add(processVo);
    }
    IPage<ProcessVo> page = new Page<>(pageParam.getCurrent(), pageParam.getSize(), query.count());
    page.setRecords(processVoList);
    return page;
}

@Override
public IPage<ProcessVo> pagePending(Page<Process> pageParam) {
    TaskQuery query = taskService.createTaskQuery()
            .taskAssignee(LoginUserInfoHelper.getUsername())
            .orderByTaskCreateTime()
            .desc();
    int begin = (int) ((pageParam.getCurrent() - 1) * pageParam.getSize());
    int size = (int) pageParam.getSize();
    List<Task> taskList = query.listPage(begin, size);
    List<ProcessVo> processVoList = new ArrayList<>();
    for (Task task : taskList) {
        ProcessInstance processInstance = runtimeService.createProcessInstanceQuery()
                .processInstanceId(task.getProcessInstanceId())
                .singleResult();
        String businessKey = processInstance.getBusinessKey();
        if (businessKey == null) {
            continue;
        }
        Process process = baseMapper.selectById(Long.parseLong(businessKey));
        ProcessVo processVo = new ProcessVo();
        BeanUtils.copyProperties(process, processVo);
        processVo.setTaskId(task.getId());
        processVoList.add(processVo);
    }
    IPage<ProcessVo> page = new Page<>(pageParam.getCurrent(), pageParam.getSize(), query.count());
    page.setRecords(processVoList);
    return page;
}
